Price range: $143.07 through $161.65 EX GST
Side View NEON in 6 x 12mm form size, ideal for discrete linear light with 3 Step Macadams consistency
Price is for Standard reel Lengths of 5 Metre reels. Single serial run per driver is 19 metres in Constant Current, Serial run of 13 metres available in a Constant Volatge Version.
| Price Break Qty | Discounted Price |
|---|---|
| 1 - 9 | $143.07 |
| 10 - 49 | $138.78 |
| 51 - 100 | $128.76 |
| 101 - 500 | $108.73 |
| 501 - 1000 | $100.15 |
Side View Silicone Neon SL0612 – Premium Lumileds 3-Step MacAdam, 5-Year Warranty
The SL0612 Side View Silicone Neon is a high-performance, flexible LED lighting solution designed for architectural, signage, and decorative applications where uniform side-emitting light is essential. Featuring Lumileds LEDs within a 3-step MacAdam bin for outstanding colour consistency, this IP67-rated strip delivers exceptional reliability and weather resistance for both indoor and outdoor installations.
Key Features
Premium Light Quality – High CRI >90 for superior colour rendering.
Multiple Outputs – Available in low power 5W/m and medium power 10W/m configurations.
CCT Options – Wide range of colour temperatures from 2100K to 6150K, including 2700K, 3000K, and 4000K standard options.
Uniform Side Emission – Perfect for side-lit channel letters, coves, and contours.
IP67 Protection – Resistant to dust, water, UV, solvents, and saltwater for long-term outdoor use.
Flexible Design – Horizontal bending with a minimum radius of 300mm.
Long Runs – Up to 19m (5W in Constant Current) or 13m (10W in Constant Current) per single feed for white CCTs.
Cuttable Every 50mm – Allows precise length customisation on-site.
Extended Lifespan – >50,000 hours LM80-compliant performance.
Warranty – 5-year limited warranty for peace of mind.
Technical Specifications
Voltage: DC 24V
Power Options: 5W/m or 10W/m
Luminous Flux: 214–431 lm/m (white CCT models)
Cut Length: 50mm
Operating Temperature: -25°C to +45°C
Construction: UV-resistant silicone body, solvent and saltwater resistant
Dimensions: 6mm (width) × 12mm (height)
Applications
Architectural outlines and façade lighting
Retail, hospitality, and interior feature lighting
Signage and channel letter side illumination
Landscape and pathway accents
Accessories
End caps (IP67/IP44), mounting clips, aluminium or stainless steel profiles, waterproof connectors, and PVC cables for complete installation flexibility.
Description: 0612 NEON Led Ribbon Lumileds Side View Strip
| Part Number | CCT range | Cut length | CRI | Voltage | Lumens (lm/m) | Power (w/m) | Max serial run length (m) | Constant Current/ Constant Voltage |
| NS-SL0612-W27-5-CC | 2700K | 50mm | >90 | DC24V | 214 | 5 | 19 | Constant Current |
| NS-SL0612-W30-5-CC | 3000K | 50mm | >90 | DC24V | 215 | 5 | 19 | Constant Current |
| NS-SL0612-W40-5-CC | 4000K | 50mm | >90 | DC24V | 216 | 5 | 19 | Constant Current |
| NS-SL0612-W27-5-CV | 2700K | 50mm | >90 | DC24V | 214 | 5 | 5 | Constant Voltage |
| NS-SL0612-W30-5-CV | 3000K | 50mm | >90 | DC24V | 215 | 5 | 5 | Constant Voltage |
| NS-SL0612-W40-5-CV | 4000K | 50mm | >90 | DC24V | 216 | 5 | 5 | Constant Voltage |
| Part Number | CCT range | Cut length | CRI | Voltage | Lumens (lm/m) | Power (w/m) | Max serial run length (m) | Constant Current/ Constant Voltage |
| NS-SL0612-W27-10-CC | 2700K | 50mm | >90 | DC24V | 428 | 10 | 13 | Constant Current |
| NS-SL0612-W30-10-CC | 3000K | 50mm | >90 | DC24V | 430 | 10 | 13 | Constant Current |
| NS-SL0612-W40-10-CC | 4000K | 50mm | >90 | DC24V | 431 | 10 | 13 | Constant Current |
| NS-SL0612-W27-10-CV | 2700K | 50mm | >90 | DC24V | 428 | 10 | 5 | Constant Voltage |
| NS-SL0612-W30-10-CV | 3000K | 50mm | >90 | DC24V | 430 | 10 | 5 | Constant Voltage |
| NS-SL0612-W40-10-CV | 4000K | 50mm | >90 | DC24V | 431 | 10 | 5 | Constant Voltage |
| Weight | 0.25 kg |
|---|---|
| Dimensions | 5000 × 6 × 12 mm |
| Colour(CCT) | |
| CRI | |
| Led Voltage | |
| Led Ribbon Width | |
| Drive Output Type |
